[shortdesc]

Easy, cost-effective vehicle access control, AXIS License Plate Verifier preinstalled, Purpose-tuned for license plate recognition, Support for allow- and blocklist, Discreet, vandal- and weather-resistant, Built-in support for Axis Network Door Controllers

[/shortdesc]

[properties]

Properties	AXIS P3265-LVE-3 License Plate Verifier Kit
Description	The AXIS P3265-LVE-3 License Plate Verifier Kit is a rugged 6 MP panoramic onboard surveillance camera designed for the transportation industry. With a complete 180° or 360° overview, advanced features like Forensic WDR and OptimizedIR, and built-in cybersecurity, it ensures high-quality, secure monitoring in challenging environments.
Product Family	AXIS P3265-LVE-3 License Plate Verifier Kit
Product Type	Camera
AXIS License Plate Verifier - Features
Application
Compute platform	Edge
Licenses	Configuration
Settings	Define area of interest in scene. Allow- and blocklist logic. Barrier mode: Open to all, open to allowlisted, open to all but blocklisted. Minimum width: 130 pixels for one-row license plates; 70 pixels for two-row license plates. FIFO event log entries including thumbnail image of license plate. Up to 1000 entries on camera storage. Up to 100 000 entries on AXIS Surveillance Cards. Configurable retention time of stored events
Detection range	2.0 to 7.0 m (6.6 to 23 ft)
Vehicle speed	Up to 30 km/h (19 mph)
Detection time	Less than 1 second.
Scenarios
Typical applications	Vehicle access control In Access control, the application monitors entrances and exits of gated areas such as parking areas. The application verifies detected license plates against an allowlist or a blocklist for granting or denying access to an area. Maximum 10,000 license plates in each list. For a scenario where greater functionality and flexibility are required, use AXIS A1001 Network Door Controller. AXIS A1001 with AXIS Entry Manager software supports access rules including schedules and a more detailed event log. Multiple partner software that support a great number of credentials and features are available. License plate recognition in slow speed traffic In Freeflow, the application can detect and read license plates in slow speed traffic on larger access roads, city centers and enclosed areas like campuses, ports or airports. This allows for LPR-forensic search and LPR triggered events in a VMS such as AXIS Camera Station.
System integration
Application Programming Interface	Open API for software integration.
Event streaming	Integrates with camera event management system to enable event streaming to management software and camera actions such as I/O control, notification, and edge storage.
Supported devices	Direct integration with AXIS A1001 Network Door Controller, AXIS A91 Network I/O Relay Modules, AXIS A1601 Network Door Controller, and 2N IP Device
Languages	English

[/properties] [specifications]

Specifications	AXIS P3265-LVE-3 License Plate Verifier Kit
Camera
Image sensor	1/2.8” progressive scan RGB CMOS
Lens	Varifocal, 3.4–8.9 mm, F1.8
	Horizontal field of view: 100°–36°
	Vertical field of view: 53°–20°
	Minimum focus distance: 0.5 m (1.6 ft)
	IR corrected, remote zoom and focus, P-Iris control
Day and night	Automatic IR-cut filter
Day and night	Hybrid IR filter
Minimum illumination	With Lightfinder 2.0:
	Color: 0.1 lux at 50 IRE, F1.8/1.6
	B/W: 0.02 lux at 50 IRE, F1.8/1.6
	0 lux with IR illumination on
Shutter speed	1/66500 s to 2 s
Camera angle adjustment	Pan ±180°, tilt +75°, rotation ±175°
System on chip (SoC)
Model	ARTPEC-8
Memory	1024 MB RAM, 8192 MB Flash
Compute capabilities	Deep learning processing unit (DLPU)
Video
Video compression	H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles
	H.265 (MPEG-H Part 2/HEVC) Main Profile
	Motion JPEG
Resolution	16:9: 1920x1080 to 160x90
	16:10: 1440x900 to 160x100
	4:3: 1440x1080 to 160x120
Frame rate	With WDR: Up to 25/30 fps (60/50 Hz) in all resolutions
Frame rate	Without WDR: Up to 50/60 fps (60/50 Hz) in all resolutions
Video streaming	Up to 20 unique and configurable video streams* Axis Zipstream technology in H.264 and H.265 Controllable frame rate and bandwidth VBR/ABR/MBR H.264/H.265 Low latency mode Video streaming indicator
Video streaming	*: We recommend a maximum of 3 unique video streams per camera or channel, for optimized user experience, network bandwidth, and storage utilization. A unique video stream can be served to many video clients in the network using multicast or unicast transport method via built-in stream reuse functionality.
Signal-to-noise ratio	>55 dB
WDR	Forensic WDR: Up to 120 dB depending on scene
WDR	WDR – forensic capture
Multi-view streaming	2 individually cropped out view areas
Noise reduction	Spatial filter (2D noise reduction)
Noise reduction	Temporal filter (3D noise reduction)
Image settings	Saturation, contrast, brightness, sharpness, white balance,
	day/night threshold, local contrast, tone mapping, exposure
	mode, exposure zones, defogging, compression, rotation: 0°,
	180° including mirroring, text and image overlay, dynamic text
	and image overlay, privacy masks, polygon privacy mask, target
	aperture
Image processing	Axis Zipstream, Lightfinder 2.0, OptimizedIR
Pan/Tilt/Zoom	Digital PTZ, preset positions
Audio
Audio features	AGC automatic gain control
Audio features	Network speaker pairing
Audio streaming	Configurable duplex: Two-way (half duplex, full duplex)
Audio input	10-band graphic equalizer
	Input for external unbalanced microphone, optional 5 V
	microphone power
	Digital input, optional 12 V ring power
	Unbalanced line input
Audio output	Output via network speaker pairing
Audio output	Line output
Audio encoding	24bit LPCM, AAC-LC 8/16/32/48 kHz, G.711 PCM 8 kHz, G.726
	ADPCM 8 kHz, Opus 8/16/48 kHz
	Configurable bit rate
Network
Network protocols	IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, HTTP/2, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, DHCPv4/v6, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf), IEEE 802.1X (EAP-TLS), IEEE 802.1AR
Network protocols	*: This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (openssl.org), and cryptographic software written by Eric Young
System Integration
Application Programming Interface	Open API for software integration, including VAPIX®, metadata,
	and AXIS Camera Application Platform (ACAP); specifications at
	axis.com/developer-community. ACAP includes Native SDK and
	Computer Vision SDK.
	One-click cloud connection
	ONVIF® Profile G, ONVIF® Profile M, ONVIF® Profile S, and
	ONVIF® Profile T, specifications at onvif.org
	Support for Session Initiation Protocol (SIP) for integration with
	Voice over IP (VoIP) systems, peer to peer or integrated with
	SIP/PBX.
Video management systems	Compatible with AXIS Companion, AXIS Camera Station, video
	management software from Axis’ Application Development
	Partners available at axis.com/vms
Onscreen controls	Day/night shift
	Defogging
	Wide dynamic range
	Video streaming indicator
	IR illumination
	Heater
Event conditions	Application
	Audio: audio clip playing
	Device status: above operating temperature, above or below
	operating temperature, below operating temperature, within
	operating temperature, IP address removed, new IP address,
	network lost, system ready, ring power overcurrent protection,
	live stream active
	Digital audio input status
	Edge storage: recording ongoing, storage disruption, storage
	health issues detected
	I/O: digital input, manual trigger, virtual input, digital output
	MQTT: stateless
	Scheduled and recurring: schedule
	Video: average bitrate degradation, day-night mode, tampering
Event actions	Audio clips: play, stop
	Day-night mode
	Defog
	I/O: toggle I/O once, toggle I/O while the rule is active
	Illumination: use lights, use lights while the rule is active
	MQTT: publish
	Notification: HTTP, HTTPS, TCP and email
	Overlay text
	Recordings: SD card and network share
	SNMP traps: send, send while the rule is active
	Upload of images or video clips: FTP, SFTP, HTTP, HTTPS, network
	share and email
	WDR mode
Built-in installation aids	Pixel counter, remote zoom and focus, straighten image, level
Built-in installation aids	grid
Analytics
Metadata	Object data: Classes: humans, faces, vehicles (types: cars, buses,
	trucks, bikes), license plates
	Confidence, position
	Attributes: Vehicle color, upper/lower clothing color, confidence,
	position
	Event data: Producer reference, scenarios, trigger conditions
Applications	Included
	AXIS License Plate Verifier
	AXIS Video Motion Detection, active tampering alarm, audio
	detection
	Supported
	Support for AXIS Camera Application Platform enabling installation of third-party applications, see axis.com/acap
Approvals
Product markings	CSA, UL/cUL, BIS, UKCA, CE, KC, EAC, VCCI, RCM
Supply chain	TAA compliant
EMC	CISPR 35, CISPR 32 Class A, EN 55035, EN 55032 Class A,
	EN 50121-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1,
	EN 61000-6-2
	Australia/New Zealand: RCM AS/NZS CISPR 32 Class A
	Canada: ICES-3(A)/NMB-3(A)
	Japan: VCCI Class A
	Korea: KS C 9835, KS C 9832 Class A
	USA: FCC Part 15 Subpart B Class A
	Railway: IEC 62236-4
Safety	CAN/CSA C22.2 No. 62368-1 ed. 3, IEC/EN/UL 62368-1 ed. 3,
Safety	IEC/EN 62471 risk group exempt, IS 13252
Environment	IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14,
	IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66,
	IEC/EN 62262 IK10, NEMA 250 Type 4X, NEMA TS 2 (2.2.7-2.2.9)
Network	NIST SP500-267
Cybersecurity
Edge security	Software: Signed firmware, brute force delay protection, digest
	authentication, password protection, AES-XTS-Plain64 256bit
	SD card encryption
	Software: Signed firmware, brute force delay protection, digest
	authentication and OAuth 2.0 RFC6749 OpenID Authorization
	Code Flow for centralized ADFS account management, password
	protection, AES-XTS-Plain64 256bit SD card encryption
	Hardware: Secure boot, Axis Edge Vault with Axis device ID,
	signed video, secure keystore (CC EAL4+ certified hardware
	protection of cryptographic operations and keys)
	Secure element (CC EAL 6+), secure keystore, secure bootSecure
	boot, Axis Edge Vault with Axis device ID, signed video,
	secure keystore (CC EAL4+ certified hardware protection of
	cryptographic operations and keys)
	Secure element (CC EAL 6+), system-on-chip security (TEE), Axis
	device ID, secure keystore, signed video, secure boot, encrypted
	filesystem (AES-XTS-Plain64 256bit)Secure boot, Axis Edge Vault
	with Axis device ID, signed video, secure keystore (CC EAL4+
	certified hardware protection of cryptographic operations and
	keys)
	Hardware: , Axis Edge Vault with Axis device ID, signed video,
	secure keystore (CC EAL4+ certified hardware protection of
	cryptographic operations and keys)
	Secure element (CC EAL 6+), secure keystore, secure boot, Axis
	Edge Vault with Axis device ID, signed video, secure keystore (CC
	EAL4+ certified hardware protection of cryptographic operations
	and keys)
	Secure element (CC EAL 6+), system-on-chip security (TEE), Axis
	device ID, secure keystore, signed video, secure boot, encrypted
	filesystem (AES-XTS-Plain64 256bit), Axis Edge Vault with Axis
	device ID, signed video, secure keystore (CC EAL4+ certified
	hardware protection of cryptographic operations and keys)
	Hardware: , signed video, secure keystore (CC EAL4+ certified
	hardware protection of cryptographic operations and keys)
	Secure element (CC EAL 6+), secure keystore, secure boot, signed
	video, secure keystore (CC EAL4+ certified hardware protection
	of cryptographic operations and keys)
	Hardware: Axis Edge Vault cybersecurity platform
	Secure element (CC EAL 6+), secure keystore, secure bootAxis
	Edge Vault cybersecurity platform
	Secure element (CC EAL 6+), system-on-chip security (TEE),
	Axis device ID, secure keystore, signed video, secure boot,
	encrypted filesystem (AES-XTS-Plain64 256bit), signed video,
	secure keystore (CC EAL4+ certified hardware protection of
	cryptographic operations and keys)
Network security	IEEE 802.1X (EAP-TLS)b , IEEE 802.1AR, HTTPS/HSTSb , TLS v1.2/v1.3b , Network Time Security (NTS), X.509 Certificate PKI, IP address filtering IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2)b , IEEE 802.1AR, HTTPS/HSTSb , TLS v1.2/v1.3b , Network Time Security (NTS), X.509 Certificate PKI, IP address filtering
Network security	*: This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (openssl.org), and cryptographic software written by Eric Young
Documentation	AXIS Hardening Guide
	AXIS Vulnerability Management Policy
	AXIS Security Development Model
	AXIS OS Software Bill of Material (SBOM)
	To download documents, go to axis.com/support/cybersecurity/resources
	To read more about Axis cybersecurity support, go to axis.com/cybersecurity
General
Casing	IP66-, NEMA 4X- and IK10-rated
	Polycarbonate hard-coated dome
	Polycarbonate (PC) casing and weathershield
	Color: white NCS S 1002-B
	For repainting instructions, go to the product’s support
	page. For information go to
	axis.com
Mounting	Mounting bracket with junction box holes (double-gang,
	single-gang, 4” square, and 4” octagon)
	¼”-20 UNC tripod screw thread
Power	Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3
Power	Typical 4.8 W, max 10.7 W
Connectors	Network: RJ45 10BASE-T/100BASE-TX PoE
	I/O: 4-pin 2.5 mm terminal block for 1 digital input and 1 output
	(12 V DC output, max. load 25 mA)
	Audio: 4-pin 2.5 mm terminal block for audio in and out
IR illumination	OptimizedIR with power-efficient, long-life 850 nm IR LEDs
IR illumination	Range of reach 40 m (130 ft) or more depending on the scene
Storage	Support for microSD/microSDHC/microSDXC card
	Support for SD card encryption (AES-XTS-Plain64 256bit)
	Recording to network-attached storage (NAS)
	For SD card and NAS recommendations see axis.com
Operating conditions	(-40°C to 50 °C) (-40 °F to 122 °F)
	Maximum temperature according to NEMA TS 2 (2.2.7): 74 °C
	(165 °F)
	Start-up temperature: -30 °C to 50 °C (-22 °F to 122 °F)
	Humidity 10–100% RH (non-condensing)
Storage conditions	(-40 °C to 65 °C (-40 °F to 149 °F)
Storage conditions	Humidity 5–95% RH (non-condensing)
Dimensions	Without weathershield:
	Height: 104 mm (4.09 in)
	ø 149 mm (5.87 in)
Weight	With weathershield:
Weight	800 g (1.8 lb)
System tools	AXIS Site Designer, AXIS Device Manager, product selector,
	accessory selector, lens calculator
	Available at axis.com
Languages	English, German, French, Spanish, Italian, Russian, Simplified
	Chinese, Japanese, Korean, Portuguese, Polish, Traditional Chinese
	English, German, French, Spanish, Italian, Russian, Simplified
	Chinese, Japanese, Korean, Portuguese, Polish, Traditional
	Chinese, Dutch, Czech, Swedish, Finnish, Turkish, Thai,
	Vietnamese
Sustainability
Substance control	PVC free in accordance with JEDEC/ECA Standard JS709
	RoHS in accordance with EU RoHS Directive 2011/65/EU/ and
	EN 63000:2018
	REACH in accordance with (EC) No 1907/2006. For SCIP UUID,
	see echa.europa.eu
Materials	Screened for conflict minerals in accordance with OECD
	guidelines
	To read more about sustainability at Axis, go to
	axis.com/about-axis/sustainability

[/specifications] [accesories]

Optional accessories

• AXIS TP3201-E Recessed Mount
• AXIS TP3103–E Pendant Kit
• AXIS T94K01D Pendant Kit
• AXIS T8355 Digital Microphone 3.5 mm
• AXIS Surveillance Cards

[/accesories]

Please check the supported countries Visit www.axis.com for supported products and application download. Discreet outdoor, HDTV / 1080p, day/night, dust- and IK10 vandal-resistant fixed dome camera with built-in AXIS License Plate Verifier application. Detect and verify vehicles in single lanes with speed up to 30 km/h (19 mph) in 2 to 7 meter distance (7 to 23 feet) to allow vehicle entry/exit into a controlled area. I/O port for direct control, built-in block and allow lists of up to 1000 license plates. License plate reading time less than 1 second. OptimizedIR, Forensic WDR, Lightfinder, shock detection, IK10, IP66. Operation temperature -40 degreeC to +50 degreeC (-40 degreeF to 122 degreeF). Includes mounting bracket for wall/ceiling or junction boxes. License plate verification day and night. Powered by IEEE 802.3af Type 1 Class 3 midspan (PoE). Midspan not included.

Feature	AXIS P3265-LV	AXIS P3265-LVE	AXIS P3265-LVE-3	AXIS P3265-V	AXIS P3267-LV	AXIS P3267-LVE	AXIS P3268-LV	AXIS P3268-LVE
Max video resolution	1920x1080	1920x1080	1920x1080	1920x1080	2592x1944	2592x1944	3840x2160	3840x2160
Horizontal field of view	100-36	100-36 / 35-15	100-36	100-36	104 - 40	104 - 40	100 - 53	100 - 53
OptimizedIR	✓	✓			✓	✓	✓	✓
Day and Night functionality	✓	✓	✓	✓	✓	✓	✓	✓
Remote zoom	✓	✓	✓	✓	✓	✓	✓	✓
Remote focus	✓	✓	✓	✓	✓	✓	✓	✓
Audio Support	✓				✓	✓	✓	✓
Alarm inputs/outputs	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1
Lightfinder	Lightfinder 2.0	Lightfinder 2.0	Lightfinder 2.0	Lightfinder 2.0	Lightfinder 2.0	Lightfinder 2.0	Lightfinder 2.0	Lightfinder 2.0
Wide dynamic range	Forensic WDR	Forensic WDR	Forensic WDR	Forensic WDR	Forensic WDR	Forensic WDR	Forensic WDR	Forensic WDR
Zipstream	✓	✓	✓	✓	✓	✓	✓	✓
Vandal rating	IK10	IK10	IK10	IK10	IK10	IK10	IK10	IK11
Analytics compute capability	DLPU	DLPU	DLPU	DLPU	DLPU	DLPU	DLPU	DLPU
Axis Edge Vault	✓	✓	✓	✓	✓	✓	✓	✓

Axis P32 Series Dome Cameras
